HPC Aircenter 13
The Aircenter 13 is a combined Compressor, Dryer & Receiver Package. It comes with a 10 bar operating pressure and features the high energy efficient ‘Sigma’ air end and drive system. It has a fully programable onboard controller which provides easy usage. The automatic water drain saves time in the workshop and the built-in refrigerant dryer is an essential addition to the product as a whole. The unit is also completely service friendly. The easily removable housing cover provides component accessibility and it features a new maintenance-free drive belt, guaranteeing optimum power on top of reducing service costs.
- Made in Germany.
- Supplied with a 5-year warranty (Subject to service agreement).
- 10 bar operating pressure.
- 7.5kW – 38.1 cfm (1.08m3 /min)
- Highly energy efficient ‘Sigma’ air end and drive system.
- Super-premium efficiency IE4 motor.
- Fully programable onboard controller.
- SC2IO (Sigma Control 2) * Low oil level monitoring with safety shutdown.
- Housed within a super silencing acoustic enclosure 65dB(A)
- Integrated refrigerant dryer.
- Automatic water drain.
- 440v 3-phase.
Galvanized Receiver Capacity
270L
WxDxH
750x1335x1880
